SC APC Fiber Optic Fast Connector with 55mm Length and 4N Fiber Tension for G652/G657 Fiber

  • SC APC Fiber Optic Fast Connector with 55mm Length and 4N Fiber Tension for G652/G657 Fiber
  • SC APC Fiber Optic Fast Connector with 55mm Length and 4N Fiber Tension for G652/G657 Fiber
  • SC APC Fiber Optic Fast Connector with 55mm Length and 4N Fiber Tension for G652/G657 Fiber
  • SC APC Fiber Optic Fast Connector with 55mm Length and 4N Fiber Tension for G652/G657 Fiber
Place of Origin Guangdong, China
Brand Name KCO
Certification ISO9001, RoHS
Model Number KCO-FC-55-SCA
Minimum Order Quantity Negotiation
Price Negotiation
Packaging Details PE bag, carton box, wooden pallet
Delivery Time 2~5 days after get payment
Payment Terms Western Union,T/T,L/C
Supply Ability 100,000pcs/month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
P/N KCO-FC-55-SCA Color Green
Insertion Loss 0.3dB Return Loss 40dB
3D Pass Polishing Type APC
Fiber Mode Single Mode Fiber Type G652, G657
Cable Indoor Cable, Ftth Drop Cable Length 55mm
Fiber Tension 4N Cable Tension 40N
Highlight

SC APC Fiber Optic Fast Connector

,

FTTO Fiber Optic Fast Connector

,

FTTH SC APC Fast Connector
Leave a Message
Product Description
Viettel FTTH SC APC Fiber Optic Fast Connectors Length 55mm Fiber Tension 4N
The SC/APC Fiber Optic Fast Connectors are factory pre-polished, field-installable connectors that eliminate the need for hand polishing. These connectors feature proven mechanical splice technology for precision fiber alignment, a factory pre-cleaved fiber stub, and proprietary index-matching gel for immediate low loss termination with single-mode or multimode optical fibers.
Applications
  • Fiber to The Home (FTTH)
  • Fiber to the building (FTTB)
  • Fiber To The Office (FTTO)
  • Cable Television (CATV)
  • Asynchronous Transmission Mode (ATM)
  • Passive optical networks (PON)
  • Local Area Networks (LAN)
Key Features
  • Fast and easy installation with no special tools required
  • Field-reconnectable design
  • No epoxy or polishing required
  • Compatible with 3mm drop cable and 3x2mm flat cable
  • Low reflection and high reliability with no matching gel
  • Internal splicing point with no additional work required
  • One-touch, push-pull assembly system
  • Fusion splice protection with heat shrinkable tube
  • 100% quality tested for extended lifespan and reduced maintenance
SC APC Fiber Optic Fast Connector with 55mm Length and 4N Fiber Tension for G652/G657 Fiber 0
Technical Specifications
Item KCO-FC-55-SCA
Suitable Cable OD 2.0mm, 3.0mm, 0.9mm indoor
2*3mm drop cable
Optical fiber diameter 125μm
Tight buffer diameter 900μm
Fiber mode Single & multi mode
Operation time About 120s (no fiber cut)
Insert loss ≤ 0.3dB (1310nm & 1550nm)
Return loss > 40dB
Tensile strength >50 N
Operating temperature -40~+75°C
On-line tensile strength (20 N) IL ≤ 0.2dB
Mechanical durability (500 times) IL ≤ 0.2dB
Drop-off test (4m height, 3 directions) IL ≤ 0.2dB
Delivery Timeline
Material Preparation Time: 3 days (or inventory)
Production & Assembly Time: 7 days
Testing & Packaging Time: 2 days
Total Delivery Time: 12 days for 50,000pcs (faster delivery negotiable)
SC APC Fiber Optic Fast Connector with 55mm Length and 4N Fiber Tension for G652/G657 Fiber 1
OEM/ODM Services
We offer custom branding options for cables, packaging, labels, and other components. Contact our sales team for personalized solutions.
Packaging Options
  • Standard Export Packing
  • Carton box
  • Wooden box
  • Wooden pallet
Shipping Methods
International express (UPS, TNT, DHL), international air (CA, AA, EA), and sea freight available. Standard export ports include Shenzhen, Hongkong, Ningbo, with airports in Shenzhen, Hongkong, Hangzhou, and Shanghai.
