IP67 Water-proof Outdoor SC/APC LC Duplex Fiber Optic Adapter for FTTA Applications

  • IP67 Water-proof Outdoor SC/APC LC Duplex Fiber Optic Adapter for FTTA Applications
  • IP67 Water-proof Outdoor SC/APC LC Duplex Fiber Optic Adapter for FTTA Applications
  • IP67 Water-proof Outdoor SC/APC LC Duplex Fiber Optic Adapter for FTTA Applications
Place of Origin Guangdong, China
Brand Name KCO
Certification ISO9001, RoHS
Model Number KCO-OptiTap-ADT-SCA
Minimum Order Quantity Negotiation
Price Negotiation
Packaging Details PE bag, carton box, wooden roll
Delivery Time 2~5 days after get payment
Payment Terms Western Union,T/T,L/C

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
P/N KCO-OptiTap-ADT-SCA Application Outdoor
Protection Level IP67 Insertion Loss 0.2dB
Return Loss 55dB Cover Plastic
Color Black Connector SC Type (APC, UPC, PC)
Highlight

OptiTap Fiber Optic Adapter Socket

,

SC LC Optical Patch Cord
Leave a Message
Product Description
SC/UPC SC/APC LC Duplex Water-proof Outdoor Optitap Adapter Socket
SC LC Outdoor Water-proof OptiTap Fiber Optic Adapter Socket For FTTA Splice Closure Box. The OptiTap connector end incorporates an SC type connection within a slim, sealed, threaded polymer housing allowing easy connection to either a multi port terminal or in-line extension receptecal.
Key Features
Cost effective, easy, environmental seal and mechanical protection for 1 fiber simple SC style connections. Special fool-proofing design ensures blind-mating function for quick installation solutions.
  • Complies with IEC, Telcordia-GR-326-Core standards
  • Available in different sizes & color boot options
  • Low insertion loss and high return loss
  • 100% interferometer measurement
  • Compatible with Corning Opitap-SC and similar products
  • Works with flat drop or round cable, armored or non-armored
Applications
  • Telecommunication networks
  • Local area networks
  • CATV
  • Active device termination
  • Data center system networks
  • PON
  • Military applications
Patch Cord Specifications
Parameters Standard Fiber Cable Assemblies
Connector Side A: SC with armored
Side B: LC, SC, ST, FC, MPO/MTP, ODVA connector, DLC(duplex LC), NSN, Ericson, Huawei
Fiber count 2 cores, 4 cores, 6 cores, 8 cores, 12 cores
Fiber Type SM G.652D G.657A (A1, A2, B3, ...)
MM OM1 OM2 OM3 OM4 OM5
Jacket Materials LSZH TPU PE
Cable diameter 4.8mm, 5.0mm, 5.5mm, 6.0mm, 6.5mm, 7.0mm
Testing Wavelengths SM: 1310±30nm, 1550±30nm
MM: 850±30nm, 1300±30nm
Insertion Loss(dB) ≤ 0.3dB(PC/UPC/APC)
≤ 0.3dB(UPC)
Return Loss(dB) ≥45dB (PC/UPC)
≥55dB (APC)
≥35dB (UPC)
Exchange ability ≤ 0.2dB
Operating Temperature -14℃~+85℃
Storage Temperature -40℃~+85℃
Technical Parameters
  • Connector types: LC/UPC, SC/UPC, FC/UPC, ST/UPC, LC/APC, SC/APC, FC/APC, ST/APC
  • Insertion Loss: ≤0.2dB, ≤0.3dB
  • Return Loss: ≥50dB, ≥60dB
  • Fiber type: Single-mode (G652D, G655, G657A1, G657A2, G657B3), Multi-mode (OM1, OM2, OM3, OM4, OM5)
  • Operating wavelength: 1310, 1550nm, 850nm, 1490um
  • Test wavelength: 1310,1550nm
  • Repeatability: ≤0.1dN
  • Interchangeability: ≤0.2dB
  • Durability: ≤0.2dB
  • Operating Temperature: -40°C ~ +85°C
  • Storage Temperature: -40°C ~ +85°C
Product Images
IP67 Water-proof Outdoor SC/APC LC Duplex Fiber Optic Adapter for FTTA Applications 0
OEM/ODM Service
We offer custom branding options for cables, packaging, labels, and more. Our OEM and ODM services are available to meet your specific requirements.
IP67 Water-proof Outdoor SC/APC LC Duplex Fiber Optic Adapter for FTTA Applications 1
Packaging & Shipping
  • Standard export packaging: carton box, wooden box, wooden pallet
  • Shipping options: International express (UPS, TNT, DHL), International air freight, Sea freight
