Multimode OM2 50/125 12-96 Cores Loose Tube Figure 8 Optical Fiber Cable Self-Supporting Aerial GYTC8A Fiber Optic Cable

The Aerial Figure 8 Loose Tube Optical Fiber Outdoor Cable GYTC8A is a typical 8-figure self-supporting aerial fiber optic cable with an aluminum-polyethylene (APL) moisture barrier. It is designed specifically for aerial deployment scenarios that require no additional messenger wire.

The cable complies with industry standards YD/T 1155-2 and IEC 60794-1, and is widely used in last-mile access, metropolitan area network aerial lines, and similar deployments.

Its integrated "8" cross-section unites the optical transmission unit and the high-tensile galvanized steel messenger within one continuous PE outer sheath, making it a cost-efficient, high-reliability workhorse for global telecom aerial network construction.

The Multimode OM2 GYTC8A is a self-supporting 8-figure aerial multimode fiber optic cable that combines OM2 multimode transmission characteristics with the GYTC8A's integrated aerial mechanical structure. It is designed for outdoor short-to-medium distance high-speed optical interconnection scenarios. The GYTC8A Figure-8 Aerial Outdoor cable supports capacities from 2 fibers up to 144 fibers.

• G — Outdoor communication optical cable
• Y — Stranded PBT loose tubes, gel-filled
• T — Self-supporting
• 8 — Figure-8 cross-section
• A — APL (aluminum-polyethylene laminate) moisture barrier

1. 250 µm fibers in PBT loose tubes with water-blocking jelly.
2. Loose tubes and fillers stranded around a central steel strength member.
3. Cable core wrapped with APL tape (moisture/oxygen barrier).
4. Fiber lobe and stranded steel messenger wire molded into one PE figure-8 sheath.
5. No separate messenger strand required.

• Ultra-high tensile performance
• S-Z reverse stranding layer
• Full-section water-blocking system
• Dual barrier armored protection layer
• Integrated 8-shaped outer sheath system
• Integrated UV-resistant HDPE outer sheath

• Data center park interconnection: Aerial high-speed links between different buildings in the park, supporting 1G/10G short-distance interconnection with no need for buried pipeline construction.
• Campus and industrial park network: Aerial deployment of backbone links in universities, manufacturing parks, and logistics parks, with low cost and fast deployment.
• Urban residential area FTTO access: Aerial laying of the last 100-meter high-speed optical fiber link in older communities, matching existing overhead pole line resources.
• Temporary event network deployment: Rapid erection of temporary high-speed optical lines for large exhibitions, sports events, and outdoor performances, with no complex fixing required.
• Outdoor monitoring system networking: Aerial connection of high-definition surveillance cameras distributed along roads and scenic spots, supporting stable high-bandwidth video transmission.

We offer full OEM and ODM services. If you would like to display your own brand logo on the goods — such as on the cable, package bag, label, or anywhere else — we can accommodate your requirements. Our OEM and ODM service is always ready to assist.

According to standard export packing:

• Carton box
• Wooden box
• Wooden pallet

• International express such as UPS, TNT, DHL, etc.
• International air: CA, AA, EA, etc.
• By sea
