2.0m 2.0mm Multimode Fiber Optic Patch Cord with 62.5/125 Core for High Density Connectivity

  • 2.0m 2.0mm Multimode Fiber Optic Patch Cord with 62.5/125 Core for High Density Connectivity
  • 2.0m 2.0mm Multimode Fiber Optic Patch Cord with 62.5/125 Core for High Density Connectivity
  • 2.0m 2.0mm Multimode Fiber Optic Patch Cord with 62.5/125 Core for High Density Connectivity
  • 2.0m 2.0mm Multimode Fiber Optic Patch Cord with 62.5/125 Core for High Density Connectivity
Place of Origin Guangdong, China
Brand Name KCO
Certification ISO9001, RoHS
Model Number LC-LC-UPC-MM-2.0mm-2.0m
Minimum Order Quantity Negotiation
Price Negotiation
Packaging Details PE bag, carton box, wooden roll
Delivery Time 2~5 days after get payment
Payment Terms Western Union,T/T,L/C

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Connector 1 LC/UPC Connector 2 LC/UPC
Mode Multi Mode Cover PVC, LSZH
Insertion Loss 0.2dB Return Loss 55dB
Diameter 2.0mm Length 1.0m, 2.0m, 3.0m,4.0m
Core 62.5/125
Highlight

fiber optic pigtail cables

,

patch cord pigtail
Leave a Message
Product Description
PVC LSZH 2.0m Fiber Optic Patch Cord MM Multimode LC/UPC-LC/UPC 2.0mm
Kocent Optec Limited provides OEM service for all fiber optic patch cables, including FC, LC, SC, ST, MT-RJ, E2000, MPO, MTP, ESCON, FDDI, DPLC, LC Uniboot, and SC Uniboot connectors. Our LC/UPC-LC/UPC optical fiber patch cords offer high optical performance while saving 50% of operation space, making them ideal for data center high-density connectivity.
Fiber Optic Patch Cord Overview
A fiber optic patch cord is a cable terminated with connectors at both ends for rapid connection to CATV, optical switches, or telecom equipment. These durable cables provide essential interconnection between optical transmission equipment and patch panels in wiring closets.
Key Features
  • High return loss with low insertion loss
  • Excellent exchangeability & durability
  • Reliable and stable performance
  • UL-rated plastic housing
  • Multimode (MM) based on 50/62.5-125um fiber
Applications
  • Fiber optic communication networks
  • Fiber broadband access networks
  • CATV systems
  • Active device termination
  • Metro and Local Area Networks
  • Telecommunication networks
Specifications
Mode SM MM
Polish UPC APC | PC
Insertion Loss Typical ≤0.2dB
Maximum ≤0.3dB		 ≤0.25dB
Return Loss ≥50dB ≥65dB | ≥35dB
Interchangeability ≤0.2dB
Repeatability ≤0.1dB
Durability ≤0.2dB (1000 times mating)
Tensile Strength > 10kg
Temperature ≤0.2dB (-40°C to +85°C for 100 hours)
Humidity ≤0.2dB (+25°C to +65°C at 93% R.H. for 100 hours)
Ordering Options
  1. Connector type: FC, SC, LC, ST
  2. Ferrule End-face: PC, UPC, APC
  3. Core Type: Multi Mode 62.5/125
  4. Fiber Core: Duplex
  5. Cable Diameter: φ3.0mm, φ2.0mm, φ0.9mm
  6. Cable Length: 1, 2, 3 meter or customized
  7. Cable type: PVC, LSZH
2.0m 2.0mm Multimode Fiber Optic Patch Cord with 62.5/125 Core for High Density Connectivity 0 2.0m 2.0mm Multimode Fiber Optic Patch Cord with 62.5/125 Core for High Density Connectivity 1 2.0m 2.0mm Multimode Fiber Optic Patch Cord with 62.5/125 Core for High Density Connectivity 2 2.0m 2.0mm Multimode Fiber Optic Patch Cord with 62.5/125 Core for High Density Connectivity 3
OEM/ODM Service
We offer complete OEM/ODM services, including custom branding on cables, packaging bags, labels, or any other requested location.
Packing & Shipping
Standard export packing available in carton boxes, wooden boxes, or on wooden pallets. Shipping options include international express (UPS, TNT, DHL), air freight (CA, AA, EA), and sea freight.
Tags:

patch cord pigtail

fiber optic pigtail cables

fibre optic patch cable
