Mini Tube Optical Fiber Plc Splitter 2 X 4 SC APC UPC

  • Mini Tube Optical Fiber Plc Splitter 2 X 4 SC APC UPC
  • Mini Tube Optical Fiber Plc Splitter 2 X 4 SC APC UPC
Place of Origin Guangdong, China
Brand Name KCO, Kocent Optec Limited
Certification ISO9001, RoHS
Model Number KCO-Mini-2*4-SCA
Minimum Order Quantity Negotiation
Price Negotiation
Packaging Details Carton box, wooden pallet
Delivery Time 2~5 days
Payment Terms Western Union, T/T, L/C
Supply Ability 20,000 set/ month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Length 1.0m, 1.5m, 2.0m Splitter Type 2*4 2x4
Split Way 2 Way Input & 4 Way Output Connector SC/APC, LC/APC
Cable 0.9mm P/N KCO-Mini-2*4-SCA
High Light

Mini Tube Optical Fiber Plc Splitter

,

2x4 Optical Fiber Plc Splitter

,

SC APC Fiber Optic Splitter
Leave a Message
Product Description



2*4 Mini PLC Fiber Optic Splitter SC/APC Optics Fibre Splitters Green Connector 900um 0.9mm



Descriptions:

- In FTTx and PON architectures, fiber optic splitter is an important component to share the optic network with multiple users. The basic principle of fiber optic splitter is to split one optic light beam into several parts at a certain ratio.

- 1 x N PLC Splitter features guaranteed performance specifications and high reliability that surpass Telcordia requirements and is tailored for different applications and markets.

- 2x N Planar Light wave Circuit (PLC) Splitters are based on the Plasma Chemical Vapor Deposition (P-CVD) technology and its patented fabrication process for providing stable optical character.


Applications:
  • Fiber to The Home (FTTH)
  • Passive optical networks (PON)
  • Local Area Networks (LAN)
  • Cable Television (CATV)
  • Test Equipment
  • FTTX Systems
  • PON Networks
  • CATV Links
  • Optical Signal Distribution



Mini Tube Optical Fiber Plc Splitter 2 X 4 SC APC UPC 0



PLC Splitter Construction:



Mini Tube Optical Fiber Plc Splitter 2 X 4 SC APC UPC 1

Advantages of PLC Splitter:

- Suitable for multiple operating wavelengths (1260nm – 1650nm); unstinted.
- Equal splitter ratios for all branches.
- Compact configuration; smaller size; small occupation space.
- Good stability across all ratios.
- High quality; low failure rate.







Specifications:

Fiber length 1m or custom length
Connector Type Custom specified
Optical Fiber Type Corning SMF-28e fiber, G657A1 or as customized
Directivity (dB) Min * 55
Return Loss (dB) Min * 55 (50)
Power Handling (mW) 300
Operating Wavelength (nm) 1260 ~ 1650
Operating Temperature(°C) -40~ +85
Storage Temperature(°C) -40 ~ +85
Port Configuration 1x2 1x4 1x8 1x16 1x32 1x64
Insertion Loss(dB) Typical 3.6 7.1 10.2 13.5 16.5 20.5
Insertion Loss (dB) Max 4.0 7.3 10.5 13.7 16.9 21.0
Loss Uniformity (dB) 0.6 0.6 0.8 1.2 1.5 2
PDL(dB) 0.2 0.2 0.2 0.25 0.3 0.35
Wavelength Dependent Loss(dB) 0.3 0.3 0.3 0.5 0.5 0.5
Temp. Dependent Loss (-40~85 ) (dB) 0.4 0.4 0.4 0.5 0.5 0.5
Port Configuration 2X2 2X4 2X8 2X16 2X32 2X64
Insertion Loss(dB) Typical 3.8 7.4 10.8 14.2 17 21
Insertion Loss (dB) Max 4.2 7.8 11.2 14.6 17.5 21.5
Loss Uniformity (dB) 1 1.4 1.5 2 2.5 2.5
PDL (dB) 0.2 0.2 0.4 0.4 0.4 0.5
Wavelength Dependent Loss(dB) 0.8 0.8 0.8 0.8 0.8 1
Temp. Dependent Loss(-40~+85°C) 0.5 0.5 0.5 0.8 0.8 1



Product photos:







Mini Tube Optical Fiber Plc Splitter 2 X 4 SC APC UPC 2

Mini Tube Optical Fiber Plc Splitter 2 X 4 SC APC UPC 3

Mini Tube Optical Fiber Plc Splitter 2 X 4 SC APC UPC 4



Relation products:



Mini Tube Optical Fiber Plc Splitter 2 X 4 SC APC UPC 5



OEM/ODM Service:
- If you want to show your own brand LOGO on the goods such as cable, package bag, label or any where. Our OEM and ODM service is always ready to do it. Please contact with our sales team to get best support.



Mini Tube Optical Fiber Plc Splitter 2 X 4 SC APC UPC 6





Shipping:
- International express such as UPS, TNT, DHL, etc
- Internatioal air: CA, AA, EA, etc
- By sea
- Standard export sea port: Shenzhen, Hongkong, Ningbo
- Standard export airport: Shenzhen, Hongkong, Hangzhou, Shanghai
