Low Loss Fiber Optic Splitter 1X2 FTTH with FC UPC Corning Fiber Connectors

  • Low Loss Fiber Optic Splitter 1X2 FTTH with FC UPC Corning Fiber Connectors
  • Low Loss Fiber Optic Splitter 1X2 FTTH with FC UPC Corning Fiber Connectors
  • Low Loss Fiber Optic Splitter 1X2 FTTH with FC UPC Corning Fiber Connectors
Place of Origin Guangdong, China
Brand Name KCO
Certification ISO9001, RoHS
Model Number PLC-LCA-1x2 or PLC-SCA-1x2
Minimum Order Quantity Negotiation
Price Negotiation
Packaging Details Carton box
Delivery Time 3~7 days after payment
Payment Terms L/C,T/T,Western Union
Supply Ability 50,000 pcs/ month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Type 1x2 Connector FC/UPC,SC/APC,SC/UPC
Fiber 9/125 Um SMF-28e Or Customer Appoint Fiber Length 1.5m
Cable Diameter 3.0mm Insertion Loss 4.1dB
PDL(Max.) 0.3dB Return Loss 55dB
Uniformity (Max.) 1.5dB
Highlight

Planar Lightwave Circuit Splitter

,

PLC Optical Splitter
Leave a Message
Product Description
Low Loss Fiber Optic Splitter 1X2 FTTH with FC UPC Corning Fiber Connectors
Low Loss Fiber Optic PLC Splitter 1X2 FTTH with FC UPC Corning Fiber Connectors. This 1x2 fiber optic PLC splitter is available in ABS plastic box module configurations with or without connectors.
Key Features
  • Excellent Environmental Stability
  • Excellent Mechanical Stability
  • Telcordia GR-1221 and GR-1209 Compliant
  • Low Insertion Loss
  • Low Polarization Dependent Loss
Configuration Options
  • Split Ratios: 1x2, 1x4, 1x8, 1x16, 1x32, 1x64 and 2x2, 2x4, 2x8, 2x16, 2x32, 2x64
  • Un-connectorized versions available
  • Fiber jacketing: 2mm up to 3mm
  • ABS box type or metal box/module cassette type
  • Connector options: SC/UPC, SC/APC, LC/UPC, LC/APC, FC/UPC, FC/APC, ST/UPC
  • Custom connector configurations and combinations
Applications
  • Fiber to The Point (FTTX)
  • Fiber to The Home (FTTH)
  • Passive Optical Networks (PON)
  • Gigabit Passive Optical Networks (GPON)
  • Local Area Networks (LAN)
  • Cable Television (CATV)
  • Test Equipment
Product Image
Low Loss Fiber Optic Splitter 1X2 FTTH with FC UPC Corning Fiber Connectors 0
Technical Specifications
Fiber Length: 1m or custom length
Connector Type: Custom specified
Optical Fiber Type: Corning SMF-28e fiber, G657A1 or as customized
Directivity (dB) Min: 55
Return Loss (dB) Min: 55 (50)
Power Handling (mW): 300
Operating Wavelength (nm): 1260 ~ 1650
Operating Temperature (°C): -40 ~ +85
Storage Temperature (°C): -40 ~ +85
Performance Specifications
Port Configuration 1x2 1x4 1x8 1x16 1x32 1x64
Insertion Loss(dB) Typical 3.6 7.1 10.2 13.5 16.5 20.5
Insertion Loss (dB) Max 4.0 7.3 10.5 13.7 16.9 21.0
Loss Uniformity (dB) 0.6 0.6 0.8 1.2 1.5 2
PDL(dB) 0.2 0.2 0.2 0.25 0.3 0.35
Wavelength Dependent Loss(dB) 0.3 0.3 0.3 0.5 0.5 0.5
Temp. Dependent Loss (-40~85°C) (dB) 0.4 0.4 0.4 0.5 0.5 0.5
Port Configuration 2x2 2x4 2x8 2x16 2x32 2x64
Insertion Loss(dB) Typical 3.8 7.4 10.8 14.2 17 21
Insertion Loss (dB) Max 4.2 7.8 11.2 14.6 17.5 21.5
Loss Uniformity (dB) 1 1.4 1.5 2 2.5 2.5
PDL (dB) 0.2 0.2 0.4 0.4 0.4 0.5
Wavelength Dependent Loss(dB) 0.8 0.8 0.8 0.8 0.8 1
Temp. Dependent Loss(-40~+85°C) 0.5 0.5 0.5 0.8 0.8 1
OEM/ODM Services
We offer comprehensive OEM and ODM services. Custom branding options available for cables, packaging, labels, and product surfaces.
Packaging
Standard export packaging including carton boxes, wooden boxes, and wooden pallets.
Shipping Options
  • International express: UPS, TNT, DHL, etc.
  • International air freight: CA, AA, EA, etc.
  • Sea freight
